Trane Ycd Nomenclature



A Trane Model Number is used to breakdown or differentiate one product in a series from another. Serial numbers are commonly used in many different types of trane product. Letters are sometimes used along with numbers in the coding.

There is no standard format for how the letters and numbers are used. trane heating and air conditioning companies are free to decide how they want to use the package unit model number.

Trane YSC120 Pdf User Manuals. View online or download Trane YSC120 Installation Operation & Maintenance. Trane YHC120E Pdf User Manuals. View online or download Trane YHC120E Owner's Manual.

Trane Ycd Nomenclature

Trane Ycd Model Nomenclature

©2020 Trane RT-PRC023AU-EN Introduction PackagedRooftopAirConditioners Trane’s customers demand products that provide exceptional reliability, meet stringent performance requirements, and are competitively priced. Trane delivers with Precedent™. Precedent™ features cutting edge technologies: reliable compressors, Trane engineered. The Trane YCC is a now-discontinued single-packaged heating and gas/electric cooling system. The manufacturer’s most recent literature for the unit dates to 2003. Offering up to 10 SEER, this model was designed for outdoor installation on the ground or roof, or to be placed in downflow or horizontal configurations.

Trane ycd nomenclature

Trane Ycd Nomenclature

Examples of Trane Model Number

The Trane model is #TCD120C40CCA. TC: Package Cooling, Electric Heat D: Downflow 120: 10 Tons, Standard Efficiency C: Major Design Sequence 4: 460/60/3 0: ? (a description is not listed) C: Downflow Economizer and Oversize Motor C: Minor Design Sequence A: Service Digit (i don’t know exactly what this means)

Trane RTU model # SXHEC9040E76AD8D3D01GGNRTX S= Self Contained X= DX cooling,Extended Casing H= Single Zone E= 5th Developement sequence C90= 90 Tons 4= 460/60/3 XL 0= No Heat E= Design Sequence 7= 100% Exhaust w/ statitrac & 15 hp motor 6= Ex fan Drive 600 RPM A= Throw away filters D= Supply Fan HP 40 ( 2-20HP) 8= Supply Fan Drive 800 RPM D= !00% Economizer 3= VAV ( SA temp Control w/ IG Vanes) D= BAYSENS014 O= Standard Ambient Control 1= UL Approval

Trane ycd 048 nomenclatureTrane ycd serial number nomenclature

Trane Tonnage from Model Number

TTP018—1-1/2ton TTP024—2 ton TTP030—2 1/2 yon TTP036—3 ton TTP042—3 1/2 ton TTP048—4 ton

Example of Trane Model Identification

Trane Nomenclature Rooftop Units

TWE030C140b0 TW – split component heat pump compatable E – Electric furnace (like they said, heat strips are added in the field, could be anything from 10kw to 25 kw) 0 – Brazed refrigeration connection 30 is 2.5 ton like you mentioned C – Major development sequence C is standard system, E would be VS motor, P would be high eff system 1 – 220-230/1/60 (electric rating) 4 – Accurtron flow control check valve 0 – Standard insulation B – Minor design sequence (means nothing other than to the facotory) 0 – Service digit (they change these as they do “improvements” on thier stuff)

Trane model number nomenclature split into several segments. Each segment will have assigned a number of letters and digits. Trane uses their model number to identify its use in the HVAC system.

Trane Ycd075 Nomenclature

How to Decode

Trane Ycd180 Nomenclature

  • First letter: The model number starts with 4. This number represents the type of refrigerant the unit uses. 2 stands for R-22 and 4 stands for R410A.
  • Second letter. T stands for Trane.
  • The next 3 letter represents the product type. W stands for split heat pump and T stands for split cooling. The third letter equals the product family. Z = leadership – 2 stage, X = leadership, R = replacement/retail, B = basic, A = light commercial.
  • The fifth number is for unit’s Seasonal Energy Efficiency Ratio. A single number represents the SEER: 0 = 10, 1 = 11, 2 = 12, 3 = 13, 4 = 14, 5 = 15, 6 = 16, 7 = 17, 8 = 18, 9 = 19.
  • The six letter. Zero indicates the system’s connections are brazed or soldered.
  • The seven and eight number indicate tonnage. How many BTUs the unit produces in thousands. For example: 36 = 36,000 BTUs.
  • The nine letter represents the age. Any type of major modifications done to the system since it was originally manufactured explained here. Click here for more information on how to know the age of trane from serial number.
  • Number ten indicates the power supply voltage. 1 = 200-230/1/60 or 208-230/1/60, 3 = 200-230/3/60, 4 = 460/3/60.
  • The position eleven, twelve and thirteen. These numbers represent any secondary function.
  • Position fourteen stands for minor design modifications
  • The last letter is the unit part’s identifier code.

Trane Ycd Rooftop Nomenclature

The Trane Model Identification Number of a product is often featured prominently on the packaging of said product. On the physical product itself, the model number is most commonly found on the front, rear or bottom of the product or in the manual pdf.

See Also

Trane Model Number Nomenclature

Decoding the Trane model number need patience and accuracy, focus on each segments and you’ll break the code quickly. If you have any problem, please contact your local dealer or Trane sales office.
